M18 Industrial Automation Sensors 3 Wire 12V Non-Flush Inductive Switch
Product Details:
| Place of Origin: | China |
| Brand Name: | F&C |
| Certification: | CE RoHS |
| Model Number: | F3C-18KN08-N R2M |
Payment & Shipping Terms:
| Minimum Order Quantity: | negotiable |
|---|---|
| Price: | negotiable |
| Packaging Details: | Standard export Package |
| Delivery Time: | 10days after depsite |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 10000Pcs Per Month |
|
Detail Information |
|||
| Output Method: | Normal Open | Detection Distance: | 8mm |
|---|---|---|---|
| Standard Detection Object: | 24*24*1(Iron) | Operating Voltage: | 12-24VDC+/-10% |
| Response Frequency: | 800HZ | Polarity Reverse Protection: | Yes |
| Protection Grade: | IP67 | Operating Temperature: | -25~70℃ |
| Material: | PBT And Nickelled Brass | ||
| Highlight: | industrial proximity sensor,industrial optical sensor |
||
Product Description
M18 Industrial Automation Sensors 3 Wire 12V Non-Flush Inductive Switch
M18 Inductive Proximity Sensor widely used for pump truck and farm machine, dairy machine for metal postion detection. High quality and waterproof made it can be used outdoors.
Features and advantages :
1. Red protective sleeve designed, to protected it better.
2. High performance 12-24VDC Built-in amplifier .
3. All round LED indicator.
4. 0.1ms high speed response time
5. OEM order accepted.
| Length | Standard Body | Short Body | ||
| NPN NO | F3C-18KS05-N R2M | F3C-18KN08-N R2M | F3C-18ES05-N R2M | F3C-18EN08-N R2M |
| NPN NC | F3C-18KS05-N2 R2M | F3C-18KN08-N2 R2M | F3C-18ES05-N2 R2M | F3C-18EN08-N2 R2M |
| PNP NO | F3C-18KS05-P R2M | F3C-18KN08-P R2M | F3C-18ES05-P R2M | F3C-18EN08-P R2M |
| PNP NC | F3C-18KS05-P2 R2M | F3C-18KN08-P2 R2M | F3C-18ES05-P2 R2M | F3C-18EN08-P2 R2M |
| Sensing Distance | 5mm | 8mm | 5mm | 8mm |
| Standard Object | 15×15×1(iron) | 24×24×1(iron) | 15×15×1(iron) | 24×24×1(iron) |
| Response Frequency | 600Hz | |||
| Hysteresis | ≤10% sensing distance | |||
| Operating Voltage | 12~24VDC±10% (customize 5V) | |||
| Current Consumption | ≤8mA (No Load) | |||
| Load Current | 100mA Max at 24Vdc | |||
| Circuit Protection | Polarity Reverse Protection and Short-Circuit Protection | |||
| Operating Temperature | -20°C~+70°C | |||
| Material | PBTand SUS304 | |||
| Wiring method | 2M/3-wires | |||
| Protection degree | IP67 | |||
